• 4000 ANSI Lumen High brightness and 20,000:1 High Contrast
  • Exclusive Data Review Mode Showcases Text and Charts in Detail
  • SmartEco Mode Saves Lamp Power Up To 70%

Brand : Brand Logo


Brightness (ANSI lumens)
Native Resolution
GA (1024×768)
Native Aspect Ratio
Contrast Ratio (FOFO)
Display Color
30-bit (1.07 billion colors)
Light Source
Light Source Life
a. Normal 6000 hrs,
b. ECO 10000 hrs,
c. SmartEco 10000 hrs,
d. LampSave 15000 hrs


Throw Ratio 1.96~2.15
Zoom Ratio 1.1x Lens
Projection Offset (Full-Height) 110%
Keystone Adjustment 1D, (Auto)


Picture Modes 3D, Bright, Infographic,
Presentation, Spreadsheet, sRGB, User 1, User 2


Resolution Support VGA(640 x 480) to
WUXGA_RB(1920 x 1200)
Horizontal Frequency 15K~102KHz
Vertical Scan Rate 23~120KHz


Speaker (x1), 10W
Audio in (3.5mm Mini Jack) (x1)
Audio out (3.5mm Mini Jack) (x1)


Operating Temperature 0~40℃
Power Supply AC 100 to 240 V, 50/60 Hz
Typical Power Consumption (110V) 260W/110V
Acoustic Noise (Typ./Eco.)(dB) 34/29


Carry Bag Yes, 5J.J3T09.001 (optional)
Remote Control w/ Battery RCX016
Power Cord (by region) x1 (1.8M)
VGA(D-sub 15pin) Cable 1 (1.5m)
3D Glasses (Optional), DGD5
Quick Start Guide (x1) 21L
Warranty Card (by region) Yes
Universal Ceiling Mount (Optional), CM00G3


Dimensions (WxHxD) (mm) 296 x 120 x 221
Net Weight (kg) 2.3


Projection System DLP


  • Lamp in this product contains mercury. To dispose of the product or used lamps, consult your local environment authorities for regulations or see‎
  • Lamp life results will vary depending on environmental conditions and usage. Actual product’s features and specifications are subject to change without notice.
  • Offset is calculated by full screen height.
